China cheap Bobcat replacement mini skid steer loader for sale
China cheap Bobcat replacement mini skid steer loader for sale
China cheap Bobcat replacement mini skid steer loader for sale
Dimensions
Item | With Chevron Engineering Tyre | |
| Max working height H1 | 2143mm | 84.37inch |
| Max dump height H2 | 1488mm | 58.58inch |
| Total Height H | 1233mm | 48.54inch |
| Max pin height | 1884mm | 74.17inch |
| The length of the foot plate | 678 mm | 26.7inch(foot plate level) |
| Total length with bucket L ( mm) | 2206mm | 86.9inch |
| Highest point dump distance L1(mm) | 348mm | 13.7inch |
| Length without bucket L2(mm) | 1752mm | 69inch |
| Bucket width B(mm) | 980mm | 38.6inch |
| Total width B1(mm) | 1160mm | 45.67nch |
| Wheel base | 940mm | 37inch |
| Ground clearance(mm) | 118mm | 4.65inch |
| Turning radius R(mm) | 1307 mm | 51.5inch |
| Bucket dumping angle α(°) | 30 | |
| Rollback of bucket on ground β(°) | 25 | |
| Departure angle(°) | 11(foot plate level) | |
Parameter
Item | Item | ||||
Engin | Rated power(KW) | 15.4KW(21HP) | |||
| Rated speed(rpm) | 3300 | ||||
Noise (Db) | 95 | ||||
Hydraulic system | Hydraulic pressure(Mpa) | 17 | |||
| Cycle time(s) | Raise | Dump | lower | ||
4.27 | 1.34 | 3.31 | |||
Technical Parameter | Operating Load | 200 Kg | 441lb | ||
| Bucket Capacity | 0.15 m3 | 5.33(ft 3) | |||
| Max Lifting Force | 375 Kg | 827lb | |||
| Travel Speed | 0-5.5Km/h | 0-3.4mile/h | |||
| Operating Weight | 890 Kg | 1958lb(With Chevron Engineering Tyre ) | |||
Tires | 18*6.5-8 | ||||
Optional attachments:
standard bucket,digger,hydraulic grapple,4 in 1 bucket,hydraulic breaker,auger,angle blade,fork,snow blower,lawn mower,trencher and so on
