used steel excavator SY70 SY60 SY60C SY75 SY65

HYDRAULIC PARTS :travel motor assy ,pump assy, gear pump assy,    regulator assy, control valve assy (multiple valve assy),swing motor assy, and their spare part, piston, plate, cylinder block, main relief valve, pilot valve assy, bypass valve, swivel joint assy, gear, bearing, shaft.
ENGINE PARTS :cylinder head assy, cylinder block assy, crankshaft assy, camshaft, fuel injector assy, fuel pump assy, EGR cooler,  liner, piston, piston ring, pin, snap ring, turbocharger, alternator, repair kit, water pump, bearing set, exhaust valve and inlet valve, valve tappet, rocker arm---inlet&exhaust valve, timing gear, oil pressure switch(sensor), oil pump, oil cooler, fan, inlet manifold, starter assy, fuel pipe, pressure sensor
CHASSIS PARTS:track roller assy, roller assy, idler assy, idler adjust assy, shoe assy, track link assy, bolt, sprocket,crawler assembly, front idler, driving wheel.Filter, seal, repair kit.Cylinder, boom, arm, bucket, seal repair kit.
Others:pipe, hose, hydraulic tank, fuel tank, radiator assy, mudffler assy, coupling, screw, nut, grip assy, lever assy, pedal, cab assy and spare part, wiper arm assy, glass, wiper assy, seat assy, bonnet, slewing ring assy, swing bearing assy, boom assy, arm assy, link assy, bucket assy, side cutter, tooth assy.



Operation Range	Operating weight	5780kg
	Max. digging height	5705mm
	Max. dumping height	4020mm
	Max. digging depth	3965mm
	Max. vertical digging depth	3190mm
	Max. digging reach	6230mm
	Min. swing radius	2585mm
Dimensions	Transport length	5925mm
	Transport width	2005mm
	Transport height	2595mm
	Tail swing radius	1640 mm
	Min. ground clearance	330mm
Undercarriage/Working Device	Std. track shoe width	400 mm
	Bucket capacity	0.23 m3
	Track gauge	1600mm
	Boom length	3000 mm
	Arm length	1700mm
Performance	Travel speed	2.4/3.73km/h
	Swing speed	9.6 rpm
	Gradeability	35°
	Ground pressure	32.75 kPa
	Bucket digging force	45 kN
	Arm digging force	33 kN
	Fuel tank capacity	130 L
	Hydraulic tank capacity	85 L

Packing: The excavator are in nude, 20GP, 40HQ standard exporting package, or according to the

buyer's request.

Delivery: Within7 days upon receipt of down payment. Special models about 30days.
