Compact utility vehicle agriculture farm machinery multifunction best mini skid steer loader YF380 for sale

Compact utility vehicle agriculture farm machinery multifunction best mini skid steer loader YF380 for sale

Model NO.: YFL380
Price:: USD 5000.00-7000.00 / piece
Delivery: FOB
Minimum order quantity: 1 piece
Supply Ability: 78 piece / Month
Country of Origin: shanghai, any port in China
Stock Time: Within7 days upon receipt of down payment. Special Day

Quantity:

Product Description
Basic Information

Welcome to Jining Infront Construction Machinery Co.,Ltd!

Home of value that works!

Product Description

Skid steer loaders we produced have the high locomotive speed, reduce the time of reverse action and shifting action. It can reverse at the same place and the turning radius is small. The operation is simple, flexible and convenient. It is very suitable for cleaning up the warehouse, city planning, highway maintenance, etc. Also it is multifunctional. You can change the different accessories to attain the different function, for example, loading, excavating, ditching, digging, bulldozer, transit, sweep, drilling, breaking up, grasping woods, etc.

MAIN FEATURES

1. It is mainly used for the narrow workplaces and frequently changed operating places, also, it can be used for the accessorial equipment in large-scale machinery construction.

2. It is specially used for the basic establishment of city, road or construction building site, workshop, warehouse, port, board of ship and even in the cabin.

3. It’s also used for the safeguard, cleaning up and the ending of engineering in the engineering of large-scale machinery.

MAIN PERFORMANCE PARAMETRES


Item		Item
Engin	Rated power(KW)	15.4KW(21HP)
	Rated speed(rpm)	3300
Noise (Db)		95
Hydraulic system	Hydraulic pressure(Mpa)	17
	Cycle time(s)	Raise		Dump	lower
		4.27		1.34	3.31
Technical Parameter	Operating Load	200 Kg	441lb
	Bucket Capacity	0.15 m³	5.33(ft³)
	Max Lifting Force	375 Kg	827lb
	Travel Speed	0-5.5Km/h	0-3.4mile/h
	Operating Weight	890 Kg	1958lb(With Chevron Engineering Tyre )
Tires		18*6.5-8

DSC_0004 (6)-1.jpg

Main Dimension:

Item	With Chevron Engineering Tyre
Max working height H1	2143mm	84.37inch
Max dump height H2	1488mm	58.58inch
Total Height H	1233mm	48.54inch
Max pin height	1884mm	74.17inch
The length of the foot plate	678 mm	26.7inch(foot plate level)
Total length with bucket L ( mm)	2206mm	86.9inch
Highest point dump distance L1(mm)	348mm	13.7inch
Length without bucket L2(mm)	1752mm	69inch
Bucket width B(mm)	980mm	38.6inch
Total width B1(mm)	1160mm	45.67nch
Wheel base	940mm	37inch
Ground clearance(mm)	118mm	4.65inch
Turning radius R(mm)	1307 mm	51.5inch
Bucket dumping angle α(°)	30
Rollback of bucket on ground β(°)	25
Departure angle(°)	11(foot plate level)

Attachment

Packaging & Shipping

Packing: The excavator are in nude, 20GP, 40HQ standard exporting package, or according to the

buyer's request.

Delivery: Within7 days upon receipt of down payment. Special models about 30days.
