New Cheap Mini Crawler Steel Truck Excavator RC Digger 2.2T for sale Truck Digger
Main Specifications and characters:
1.Changchai ZN390Q engine with optimized silencer and air intake system offers great power,lower noise,lower fuel consumption,low emission,etc and maintenance becomes more easy.
2.Pilot controls imported from Korea makes operation more convenient and moderate.
3.High precision integrated instrument panel provides rea-time monitoring on machine performance.
4.Adopt load sensitive multi-way valve of Rexroth to reinforce synchronism of every action.
5.Reinforced rubber track greatly improves the wear-resisting ability as well as the protection to the road while walking.
6.With pilot operated foot valve,double action triple valve and pipeline,breaking hammer,hydraulic clamp and other devices are available.
Performance Paramete
| Partition | Project | YE8022 | |||
| POWERDEVICE | 3-cylinder Engine | ZN390Q | |||
| OVERALL DIMENSIONS | Total Length(mm) | 4082 | |||
| Total Width(mm) | 1200 | ||||
| Total Height(mm) | 2128 | ||||
| Ground Clearance(mm) | 458 | ||||
| Track | Track Gauge(mm) | 950 | |||
| Track Width(mm) | 230 | ||||
| Track Length (on ground)(mm) | 1250 | ||||
| Total Weight(Kg) | 2200 | ||||
| Ground Pressure(Kpa) | 38 | ||||
| PERFORMANCE | Max. Digging Height(mm) | 3714 | |||
| Max.Digging Radius(mm) | 4023 | ||||
| Max.Digging Depth(mm) | 2150 | ||||
| Max.Dumping Height (mm) | 2488 | ||||
| Slewing Angle | 360° | ||||
| Grade ability | 25° | ||||
| Travel Speed(Km/h) | 2.2 | ||||
| Bucket Capacity(m³) | 0.08 | ||||
| Bucket Width(mm) | 490 | ||||
| HYDRAULIC SYSTEM | Main Pump | Triple Pump | |||
| Main Pressure(Mpa) | 16 | ||||
| Max.RPM of the pump(r/min) | 3000 | ||||
| Pump Displacement(ml/r) | 12 | ||||
| 12 | |||||
| 6 | |||||
