diesel Mini Skid Steer Compact Utility Loadermini skid steer loader A2

diesel Mini Skid Steer Compact Utility Loadermini skid steer loader A2

Model NO.: A2
Price:: USD 10000.00-14000.00 / set
Delivery: FOB
Minimum order quantity: 1 set
Supply Ability: 100 set / Month
Country of Origin: qingdao,shanghai
Stock Time: 10-15 days after payment Days

Quantity:

Product Description
Basic Information

Product Description

diesel Mini Skid Steer Compact Utility Loadermini skid steer loader A2

Item		Performance parameter
		A1 (Wheel type)	A2 (Track type)
Engine	rated power(KW)	24.4kW 21.4 hp
	rated rotating speed/ torque	2800 rpm/96Nm
Attachment System pressure(Mpa)		20Mpa
Tipping load		730kg	900kg
Rated operating load		365kg	320kg
Bucket capacity		0.15 m³	0.15 m³
Speed		6km/h	6km/h
Fuel oil tank capacity		53 L	53L
Hydraulic oil capacity		52 L	52L
Tires/rubber track		23*8.5-12	1807240

Item	MAIN SIZE PARAMETER
Item	A1	A2
Max working height(A)	2355mm	2355mm
Max pin height(B)	2088mm	2122mm
Max flat bucket height(C)	1942mm	1976mm
Max dumping height(D)	1588mm	1622mm
Max dumping distance(F)	464mm	528mm
Wheel base(G)	817mm	1000mm
Wheel distance(P)	819mm	800mm
Bucket discharging angle(β)	43°	43°
Departure angle(α)	24°	30°
Total height(H)	1479mm	1514mm
Ground clearance(J)	195mm	230mm
Minimum turning radius(R)	1492mm	1507mm
Total length without bucket(K)	1961mm	1961mm
Total width(W)	1029mm	980mm
Bucket width(K)	1150mm	1150mm
Total length(L)(with bucket)	2438mm	2438mm
