1800kg YFE18 rubber track mini excavator prices hotsale
8T-1.8T general features:
1. The surface of the cylinder is chrome-plated and more wear-resistant. It adopts imported oil seal and the seal ring does not leak oil. The boom is made of thickened manganese steel, which is more sturdy.
2. Dozer blade, use thickened and raised dozer blade to better support and retain soil. Track and drive wheels are more wear resistant with thicker track tracks.
3. Adopting the science engine, it has the characteristics of more stable and environmentally friendly noise, low fuel consumption of all metal body, rain and sun protection.
Main feature
=Originally imported Japan Yanmar 3TNV82A diesel engine;
=Originally imported US Parker double-connecting gear pump;
=Originally imported Italian Comer walking motor and reducer;
=Originally imported US Eaton swing motor
=Originally imported Italian hydraulic main Valve;
=Originally imported Italian pilot control lever;
=Originally imported Italian Oil-sucking valve;
=Japan-made Bridgestone rubber tracks.
| Technical details | Unit | YFE18 |
| Specs | ||
| Operating Weight | kg | 1800 |
| Bucket Capacity | m³ | 0.06 |
| Bucket Width | mm | 450 |
| Boom Length | mm | 1823 |
| Arm Length | mm | 1130 |
| Performance | ||
| Swing Speed | rpm | 10 |
| Travel Speed | Km/h | 0-2.2 |
| Grade Ability | % | 25 |
| Ground Pressure | Kpa | 34 |
| Bucket Digging Force | KN | 15.2 |
| Arm Digging Force | KN | 8.7 |
| Max Traction Force | KN | 12.5 |
| Engine | ||
| Model | Option | YANMAR 3TNV88 |
| Standard | LaiDong KM385B | |
| Rated Power | Kw/rpm | 19.7/2200 |
| 18.1/2200 | ||
| Max Torque | N.m/rpm | 107.8 |
| 99.3 | ||
| Displacement | L | 1.642 |
| 1.532 | ||
| Cylinders | 3 | |
| Bore and Stroke | mm*mm | 88*90 |
| 85*90 | ||
| Cooling Type | Water | |
| Overall Dimensions | ||
| Overall Length*Width*Height | mm | 3725*990*2300 |
| Track Grounding Length | mm | 1250 |
| Track Shoe Width | mm | 230 |
| Track Gauge | mm | 740 |
| Min Ground Clerance | mm | 160 |
| Tail Swing Radius | mm | 1080 |
| Dozer Blade Width | mm | 990 |
| Operating Range | ||
| Max Digging Radius | mm | 3920 |
| Max Digging Depth | mm | 2140 |
| Max Digging Height | mm | 3330 |
| Max Dumping Height | mm | 2440 |
| Boom Offset (Left/Right) | mm | 240/460 |
| Boom Swing Angle L/R | ° | 73/47 |
| Dozer Blade Lift/Digging | mm | 228/218 |
| Configuration | ||
| Operating | Pilot Control | |
| Valve | Standard | Hydraulic control sensitive multiple valve |
| Option | US “HUSCO” Hydraulic control multiple valve | |
| Pump | Standard | Double gear pump |
| Option | Triple gear pump | |
| Track | Standard | Rubber |
| Option | Steel | |
| Auxiliary Line for attachment | Standard | Hydraulic control |
| two-way | ||
| Cabin/Shed | Standard | Shed |
| Option | No | |
